2016 Merlo TF38.7-120
€14,000.00
Technical data
Additional information
| Hours | 3939 |
|---|---|
| Kw | 90 |
| Weight | 7.4 |
Quick form
Description
- Nominal load at COG3.8 t
- Standard tyres405/70 R 24
- Centre of gravity500 mm
- Transmission typeHY
- Max. Reach horizontal3.7 m
- Capacity at full forward reach1.6 t
- Lifting height7.1 m
- Capacity at full lift height3.5 t
- Weight7.45 t
- Transport length4.49 m
- Transport width2.25 m
- Transport height2.47 m
- Travel speed40 km/h
- max. climbing ability45 %
- Engine manuf.Kubota
- Engine typeV2203EB
- Engine power90 kW
- Dimension lxwxh701 x 592 x 790 mm
- Displacement3.6 l
- Revolutions at max torque1600 rpm
- Max. torque480 Nm
- No. of cylinders4
- Cylinder bore x stroke98 x 120 mm
- Emission levelIIIB
